Mohr 80 Guillotine
About the Mohr 80 Guillotine
The Mohr 80 Guillotine, a pinnacle in paper cutting technology, is designed for precision, efficiency, and productivity. It features a hydraulic drive and an air-bed for easy paper handling, making it ideal for commercial printers, quick-print shops, and in-house printers.
Key Features and Benefits
- Hydraulic drive for precise and gentle bevel swing cut.
- Air-bed with corrosion-free table surface for easy material handling.
- Continuously adjustable clamping pressure.
Durable and Reliable Construction
The Mohr 80 is known for its sturdy construction, direct measurement for unique cutting precision, and long service life. The machine frame is optimized for stability, absorbing forces produced during cutting and ensuring maximum cutting precision.
Advanced Programming Options
The Mohr 80 Guillotine offers a wide range of programming options, making it adaptable to various cutting requirements. It integrates seamlessly into digital workflows, especially in the PLUS model.Enhanced Safety and Low Maintenance
With extensive safety equipment, low noise operation, and minimal maintenance requirements, the Mohr 80 ensures a safe and efficient working environment.Optimal Material Handling
The air-bed feature facilitates easy gliding of materials, enhancing the ease of handling and precision in cutting tasks.More Information
Mohr 80 Plus Electric Guillotine
Mohr Cutters are durable, programmable cutting machines with hydraulic drive. Commercial printers, quick-print shops, copy shops and in-house printers value not only the uncomplicated operation, but also the long service life of the cutting machine. The unique cutting precision is obtained by the sturdy construction and the direct measurement.
The precise and gentle bevel swing cut is carried out hydraulically on all of our models. This allows adjusting the dwell time of the knife in the BDC to the respective material.
Mohr 80 guillotines include an air-bed with a corrosion free table surface provides very easy gliding which makes the material easy to handle.
The clamping pressure can be continuously adjusted within a large range by means of a turning knob with scale to suit any material to be cut. A variable pre-clamping time control optimizes cutting quality when dealing with different materials. Luminous LEDs indicate the cutting line to the operator.
#
MOHR is a brand of Adolf Mohr Maschinenfabrik GmbH & Co. KG. based in Hofheim, a family owned company with over 100 years of tradition.
For decades, Adolf Mohr has been producing high speed cutters and cutters sold worldwide under the brand name POLAR.
The company is the world’s biggest supplier of high speed cutters, with over 130,000 machines produced and installed worldwide.
The company enjoys a solid reputation as an innovative and reliable partner. The dynamic growth market of digital printing has gained in every respect from the company’s undertaking only to produce the best possible products. In the small format sector, genuine, professional cutting machines are available at conditions which are very advantageous, both from a technical and economic point of view.
Benefits for the customer:
- Wide range of programming options
- Low noise
- Extensive safety equipment
- Air-bed for easy paper handling
- Easy knife changing with automatic shut-off in bottom dead center and adjustment from the front
- A machine frame with optimized stability takes the forces produced during the cutting process in the best possible way and guarantees maximum cutting precision
- Direct Positioning System for greatest cutting accuracy with electronic hand wheel
- Minimum expenditure of maintenance thanks to innovative materials
- Digital workflow integration (PLUS model option)
Key features
- Wide range of programming options
- Easy knife changing with automatic shut-off in bottom dead center and fine adjustment from the front
- A machine frame with optimized stability takes the forces produced during the cutting process in the best possible way and guarantees maximum cutting precision.
- Minimum expenditure of maintenance thanks to innovative materials
- Digital workflow integration (PLUS model option)
- MOHR guillotines include comprehensive standard equipment rather than options.
- They are available as ECO or NET models.
80 ECO Model
The machine is operated via an ergonomically arranged control panel with 5.5″ monochrome display and extra low-profile keyboard. Repeat sequences can be saved in one of 198 available memory positions and even be adapted at any time. The cutting programs are either generated manually or menu-driven and intuitive via block programming.
Functions:
- Low-profile keyboard with easy-to-understand symbols
- Menu-driven knife change
- Programming during cutting
- Block programming available
- Format tables
- 198 program memory locations
- Program information with plain text
- Cutting cycle shown with symbols
- Programmable jogging mark
- Clamping time before cutting
- Clamping without cutting
- Programmable ejector
- Protect program
- Lubrication interval signal
80 PLUS Model
The machine is operated via an ergonomically arranged 18.5″ touch-sensitive display. Repeat sequences can be saved and adapted at any time. To do so, the system has 1,998 memory positions available. The on-screen process visualization gives the operator a graphic indication of the cutting stages so that the program can be checked and so helps minimise set-up errors.
In optional digital workflow integrations, Compucut® takes the cutting data supplied as ppf or jdf files direct from the prepress stage. Compucut® generates the cutting program automatically. In order to start the cutting program automatically, the machine is equipped with a bar-code reader. This allows set-up times to be reduced to almost zero.
Additional functions as compared with ECO:
Process visualization for a graphic indication of material handling reduces the proneness to errors
Production report for acquiring the machine performance data
1,998 Program memory positions
Copy program
For digital workflow integration, the following options are available:
Prepress data is taken as a basis for generating cutting programs (P-Net Service Compucut®)
A bar-code reader facilitates easy loading of cutting program
Unmatched Precision and Efficiency
The Mohr 80 Guillotine is built for unmatched precision in cutting, thanks to its hydraulic drive and direct measurement system. It’s perfect for achieving precise cuts in high-volume printing tasks.
Robust and User-Friendly Design
Designed for heavy-duty
use, the Mohr 80 boasts a robust construction and user-friendly design, making it ideal for prolonged and intensive use in various printing settings.
- Hydraulic drive for consistent and accurate cutting
- Programmable for various cutting requirements
- Air-bed for effortless material handling
- Low noise operation, enhancing the work environment
- Comprehensive safety features for secure operation
- Optimized machine frame for stability and precision
- Minimal maintenance requirements
- Digital workflow integration in the PLUS model
Whether for commercial printing or in-house projects, the Mohr 80 Guillotine is a reliable, efficient, and precise cutting solution, designed to meet the highest standards of performance and safety.
Specifications
| Feature | Specification |
|---|---|
| Cutting Width | 800 mm |
| Feed Depth | 800 mm |
| Feeding Height, Max. | 100 mm (without false clamp plate) |
| Table Height | 900 mm |
| Clamping Pressure, Min. | 180 daN |
| Clamping Pressure, Max. | 2,700 daN |
| Backgauge Speed | 130 mm/sec (return stroke) |
| Knife Speed | 20 Cycles/min. |
| Smallest Cut | 15 mm (automatic, without false clamp plate) |
About
The Mohr 80 Guillotine stands out for its cutting-edge technology, safety features, and minimal maintenance needs. It’s an indispensable tool in a high-demand printing environment, delivering precision, efficiency, and reliability.
After Sales Service
FAQ
What types of materials can the Mohr 80 Guillotine handle?
It is suitable for a wide range of paper materials, ideal for commercial and in-house printing tasks.
What are the key safety features of the Mohr 80 Guillotine?
It includes extensive safety equipment, ensuring a safe operating environment.
How does the Mohr 80 integrate into digital workflows?
The PLUS model offers digital workflow integration, reducing setup times and enhancing efficiency.
